IPS Health Monitoring

Integrated Power Supply Health Monitoring

Monitor the power supply system

An Integrated Power Monitoring System, helps in identifying the power system failure while improving the reliability of the railway signal monitoring system. The whole process takes place before the signalling system is affected. It provides real-time analysis and monitoring of all the stations in the section along with their status.

Parameters IPS HMU Senses

Diagnostic Potential Free Contacts
Power supply values
Potential free contact of SPD

Alarms can be generated by IPS HMU

State of IPS
PCB failures
Failure to share the load
Rise of temperature
Failure to change state of charging FLOAT -BOOST

How does it work?

The data logger in the station monitors the power supply system and sends the recorded data to the central place through the logger network. This power supply data is received by the software present at the central location, and it is used to generate useful online textual alarms for taking action by maintenance staff. The same data is shown online in GUI, and offline reports are generated by the system that helps the maintenance engineer identify the required inputs for improving MTBF of the power supply system

Advantages of IPS HMU

Simplifies the identification of faulty module for power distribution in a station.
Generates a visual alarm when a fault is triggered and supports auto mail generation to configured users.
The system efficiently monitors the health of various power supply equipment to ensure timely prevention.
Remote monitoring of power supply becomes handy in a cost-effective manner.
