SSDAC/ HASSDAC Health Monitoring

SSDAC/HASSDAC Health Monitoring

SSDAC/HASSDAC HMU receives diagnostic data from SSDAC/HASSDAC. Voltage, current & Vital relays are monitored by external sensor unit and SSDAC HMU gives diagnostic data through error codes even VR and PR are dropped. These error codes are available in the reset box. These error codes are made use in generating alarms for the maintainer.

Parameters SSDAC/HASSDAC HMU receives

Receives Diagnostic data from DAC through Serial / Ethernet ports
Voltage, current & Vital relays are monitored by external sensor unit

Advantages of SSDAC/HASSDAC Health Monitoring System

Data of processor-based equipment is made available remotely to the experts for providing solution to the front-end technical staff
Reduction of failure duration [MTTR]
Helps in reduction of number of failures [MTBF]
Detection of errors / failures of Axle counter unit
Helps in root cause identification

Various Failures Detected

CPU card failures
Phase detector card failures
Relay driver card failures
Communication failures

Abnormal wheel types
Wheel sensor health
Reset errors
Power supply failures
